feat: add tables, task lists, images, alerts and syntax highlighting to Markdown

[rsubrama83]

Closes #33

What

Extends ShinyPDF.Markdown with the remaining items from #33:

• Tables: pipe tables with a bold header that repeats on every page, plus column alignment (:--, :-:, --:).
• Task lists: - [ ] / - [x] show a checkbox instead of the bullet.
• Images: data: URIs render directly. Other URLs go through the new options.ImageResolver. By default Markdown never reads files or the network. Images that are missing or can't be decoded fall back to their alt text.
• HTML entities: decoded (covered by tests). Raw HTML is still shown as plain text.
• Alerts: > [!NOTE], TIP, IMPORTANT, WARNING, CAUTION, with titles and colors configurable through options.AlertStyles.
• Syntax highlighting: regex-based, with built-in rules for C#, JS/TS, JSON, XML/HTML, CSS, SQL, Python, Shell, PowerShell and YAML. These are available as templates in SyntaxLanguages. Custom languages are added via new SyntaxLanguage(...).Rule(...), colors are set through options.SyntaxColors.
• Mermaid / LaTeX: no built-in renderer. The new options.CodeBlockRenderers["mermaid"] = (container, code) => ... hook lets consumers plug in their own rendering.

Behavior change: pipe tables and task lists were plain text before and now render as tables and checkboxes. No public API is removed or changed.

Verification

• dotnet build src/ShinyPDF.slnx: 0 errors
• dotnet test src/ShinyPDF.UnitTests: 215 passed (30 new Markdown tests)
• MarkdownExtendedFeatures example rendered and checked visually
• dotnet pack for ShinyPDF.Markdown succeeds

🤖 Generated with Claude Code

[Copilot]

🟡 Changes recommended

Unresolved rendering defects can prevent PDF generation and produce incorrect output.

5 open findings

• Propagate alignment to individual wrapped text lines · New
• Decode images before selecting the image rendering path · New
• Preserve enclosing link URL for rendered images · New
• Bound image height to prevent oversized PDF layout · New
• Match full unquoted variable names before short rules · New

What changed in this PR

Extends ShinyPDF.Markdown with advanced Markdown rendering for the fluent PDF API, addressing #33.

Changes:

• Adds tables, task lists, alerts and resolver-backed images.
• Adds configurable syntax highlighting and custom code-block renderers.
• Expands tests, examples and documentation.

File	Description
src/​ShinyPDF.UnitTests/​MarkdownTests.cs	Tests new rendering features and highlighting.
src/​ShinyPDF.Markdown/​SyntaxTokenKind.cs	Defines highlighting categories.
src/​ShinyPDF.Markdown/​SyntaxLanguages.cs	Provides built-in language rules.
src/​ShinyPDF.Markdown/​SyntaxLanguage.cs	Implements configurable regex tokenization.
src/​ShinyPDF.Markdown/​PackageReadme.md	Updates supported-feature documentation.
src/​ShinyPDF.Markdown/​MarkdownRenderer.cs	Implements the new rendering paths.
src/​ShinyPDF.Markdown/​MarkdownOptions.cs	Adds styling, image and renderer options.
src/​ShinyPDF.Markdown/​MarkdownExtensions.cs	Updates public API documentation.
src/​ShinyPDF.Markdown/​MarkdownAlertStyle.cs	Defines configurable alert styling.
src/​ShinyPDF.Examples/​MarkdownExamples.cs	Demonstrates extended Markdown features.
docs/​how-to/​render-markdown.md	Documents configuration and usage.
AGENTS.md	Updates Markdown implementation status.

🧠 Review effort: Balanced

---

Give feedback about Copilot approvals in this survey to enter a drawing for a $150 gift card.

[Copilot]

🟡 Changes recommended

Image decoding and syntax highlighting lack resource limits for untrusted Markdown.

2 open findings

• Limit decoded image pixels before bitmap allocation · New
• Add regex timeout and safe fallback for highlighting · New

5 resolved since last review

• Match full unquoted variable names before short rules
• Bound image height to prevent oversized PDF layout
• Preserve enclosing link URL for rendered images
• Decode images before selecting the image rendering path
• Propagate alignment to individual wrapped text lines

Previously missed (3)

In code that hasn't changed since last review

Preserve explicit left alignment in RTL tables

src/​ShinyPDF.Markdown/​MarkdownRenderer.cs:330

Explicit left-aligned columns (:--) map to null, and ComposeText never calls AlignLeft(). Under ContentFromRightToLeft(), a null alignment defaults to right (src/ShinyPDF/Elements/Text/TextBlock.cs:56-63), so these columns ignore their Markdown alignment. Map TableColumnAlign.Left explicitly and apply text.AlignLeft(). Update the tests that expect null for these cells and add a right-to-left rendering case.

Treat empty keyword and type lists as no-ops

src/​ShinyPDF.Markdown/​SyntaxLanguage.cs:53

An empty Keywords() or Types() list registers a zero-width regex instead of doing nothing. If a string rule is added afterward, the empty rule can win at an opening quote; Tokenize skips that match, and regex iteration advances past the quote before the string rule can match it. Treat an empty word list as a no-op so it cannot suppress later highlighting rules.

Preserve capture numbering across highlighting rules

src/​ShinyPDF.Markdown/​SyntaxLanguage.cs:94

Combining independently validated patterns changes their numeric backreferences because capture numbering is shared. For example, (a)\1 and (b)\1 each match doubled letters alone, but the second rule's \1 now refers to the first rule's capture, so bb is not highlighted. Preserve each rule's capture semantics, for example by matching regexes independently and selecting the earliest match, with rule order breaking ties. Add a regression test with both rules.

🧠 Review effort: Balanced

---

Give feedback about Copilot approvals in this survey to enter a drawing for a $150 gift card.

[Copilot]

🔵 Needs a closer look

Unresolved rendering and custom-highlighting correctness issues need fixes.

0 open findings

2 resolved since last review

• Add regex timeout and safe fallback for highlighting
• Limit decoded image pixels before bitmap allocation

Previously missed (3)

In code that hasn't changed since last review

Explicit left alignment falls through to null

src/​ShinyPDF.Markdown/​MarkdownRenderer.cs:330

Explicit left alignment (:--) falls through to null. In a document using ContentFromRightToLeft(), TextBlock.SetDefaultAlignment then chooses Right (src/ShinyPDF/Elements/Text/TextBlock.cs:56-63), contradicting the table's alignment marker. Map TableColumnAlign.Left to HorizontalAlignment.Left and handle it with text.AlignLeft() in ComposeText. Update the existing assertions that expect null for these cells and cover a right-to-left document.

Support percent-encoded non-base64 data URI images

src/​ShinyPDF.Markdown/​MarkdownRenderer.cs:463


Combined regexes break numbered backreferences

src/​ShinyPDF.Markdown/​SyntaxLanguage.cs:126

Combining rules into one regex changes numbered backreferences. After a (#).* rule, a string rule such as (['"]).*?\1 references the first rule's capture rather than its own quote, so valid quoted strings no longer match. Preserve each rule's capture scope, for example by compiling rules separately and selecting the earliest match with rule order breaking ties. Keep the timeout fallback and add a regression test with captures in multiple rules.

🧠 Review effort: Balanced

---

Give feedback about Copilot approvals in this survey to enter a drawing for a $150 gift card.

[InDieTasten]

LGTM
